Model | Unit | GXZQ-8 | GXZQ-10 | GXZQ-20 |
BASKET內膽 | ||||
Load capacity容量 | kg | 8 | 10 | 12 |
Loading door diameter裝載門直徑 | mm | 420 | 420 | 420 |
Wash speed洗滌速度 | rpm | 45 | 45 | 45 |
Extraction speed脫水速度 | rpm | 450 | 450 | 450 |
Cycle time工作時間 | min/cycle | 50 | 50 | 50 |
TANK溶劑箱 | ||||
Tank 1 volume溶劑箱1容積 | lt | 80 | 110 | 110 |
Tank 2 volume 溶劑箱2容積 | lt | 80 | 110 | 110 |
Tank 3 volume溶劑箱3容積 | lt | 110 | 140 | 140 |
STILL蒸餾箱 | ||||
Useful volume容積 | lt | 130 | 220 | 220 |
Still speed蒸餾速度 | lt/h | 120 | 150 | 150 |
Filtration area過濾面積 | m2 | 2.5 | 2.5 | 2.5 |
Filter specifications過濾器濾芯片數 | pcs | 21 | 21 | 21 |
Power supply電功率 | ||||
Solvent pump容積泵功率 | kw | 0.55 | 0.55 | 0.55 |
Driving motor驅動電機功率 | kw | 1.5 | 1.8 | 2.2 |
Fan motor風機功率 | kw | 0.55 | 0.55 | 0.55 |
Filter motor過濾器功率 | kw | 0.25 | 0.25 | 0.25 |
Refrigerator制冷系統(tǒng)功率 | kw | 1.5 | 2.2 | 3 |
Drying heating elements烘干加熱功率 | kw | 9 | 9 | 9 |
Still heating elements蒸餾功率 | kw | 8 | 8 | 8 |
CONNECTIONS接口 | ||||
Compressed air pressure空氣壓力 | mpa | 0.4--0.6 | 0.4--0.6 | 0.4--0.6 |
Compressed air inlet空氣進口尺寸 | mm | ф8 | ф8 | ф8 |
Water pressure水壓 | mpa | 0.2--0.4 | 0.2--0.4 | 0.2--0.4 |
Water inlet&outlet進水口、出水口尺寸 | inch | DN15 | DN15 | DN15 |
Steam pressure蒸汽壓力 | mpa | 0.4--0.6 | 0.4--0.6 | 0.4--0.6 |
Steam inlet&outlet蒸汽進口、出口蒸汽 | inch | DN15 | DN15 | DN15 |
CONSUMPTION能耗 | ||||
Air consumption壓縮空氣消耗量 | Lt/h | 6 | 8 | 8 |
Water consumption水消耗量 | Lt/h | 150 | 160 | 160 |
Steam consumption蒸汽消耗量 | Kg/h | 28 | 30 | 30 |
DIMENSION外形尺寸 | ||||
Width 寬 | mm | 1610 | 1610 | 1610 |
Depth 深 | mm | 1100 | 1150 | 1265 |
Height 高 | mm | 1700 | 1715 | 1715 |
Net weight重量 | kg | 800 | 900 | 1100 |
